Medical Oxygen Cylinder

Product Description

Materials: Every cylinder is produced from high strength aluminum alloy 6061

Finish: Standard finish is brushed body with green shoulder.

Cleaning: Cylinders are provided commercially clean.

Usage: It is ideal choice for home oxygen therapy, emergency medical services and pre-hospital care, as well as hospitals, nursing homes and other medical institutions.

Features: 40% weight reduction than steel cylinders.

No magnetism.

Interior surface treated strength corrosion resistance.

Notes:1.We can make the thread, fittings & valves or cylinder color upon request.

2.Our aluminum alloy gas cylinders can be made according to Chinese standard or international standard. We also supply the third-party inspection.

Sales Code	Specifications	Water Capacity		Diameter		Length		Thickness		Weight		Working Pressure
Sales Code	Specifications	Lts	Cu ft	mm	in	mm	in	mm	in	kgs	lbs	bar	psi
MA89-1	LWH89-0.5-15	0.5	0.018	89	3.50	187	7.36	4.5	0.18	0.56	1.23	150	2177
MA89-2	LWH89-0.6-15	0.6	0.021	89	3.50	207	8.15	4.5	0.18	0.63	1.39	150	2177
MA89-3	LWH89-0.7-15	0.7	0.025	89	3.50	227	8.94	4.5	0.18	0.70	1.54	150	2177
MA89-4	LWH89-1.0-15	1.0	0.035	89	3.50	287	11.30	4.5	0.18	0.91	2.01	150	2177
MA89-5	LWH89-1.4-15	1.4	0.049	89	3.50	367	14.45	4.5	0.18	1.18	2.60	150	2177
MA89-6	LWH89-2.0-15	2.0	0.071	89	3.50	487	19.17	4.5	0.18	1.56	3.44	150	2177
MA108-1	LWH108-2.0-15	2.0	0.071	108	4.25	365	14.37	5.6	0.22	2.20	4.85	150	2177
MA108-2	LWH108-2.5-15	2.5	0.088	108	4.25	433	17.05	5.6	0.22	2.60	5.73	150	2177
MA120-1	LWH120-2.0-15	2.0	0.071	120	4.72	320	12.60	6.1	0.24	2.65	5.84	150	2177
MA120-2	LWH120-2.5-15	2.5	0.088	120	4.72	369	14.53	6.1	0.24	2.95	6.50	150	2177
MA120-3	LWH120-2.8-15	2.8	0.0990	120	4.72	398	15.67	6.1	0.24	3.10	6.83	150	2177
MA120-4	LWH120-3.2-15	3.2	0.113	120	4.72	437	17.20	6.1	0.24	3.45	7.61	150	2177
MA140-1	LWH140-4.0-15	4.0	0.141	140	5.51	430	16.93	7.1	0.28	4.3	9.48	150	2177
MA140-2	LWH140-5.0-15	5.0	0.177	140	5.51	507	19.96	7.1	0.28	5.1	11.24	150	2177
MA140-3	LWH140-6.0-15	6.0	0.212	140	5.51	590	23.23	7.1	0.28	6	13.23	150	2177
MA140-4	LWH140-7.0-15	7.0	0.247	140	5.51	673	26.50	7.1	0.28	6.9	15.21	150	2177
MA140-5	LWH140-8.0-15	8.0	0.283	140	5.51	745	29.33	7.1	0.28	7.7	16.98	150	2177
MA159-1	LWH159-8.0-15	8	0.283	159	6.26	610	24.02	8.1	0.32	7.4	16.31	150	2177
MA159-2	LWH159-9.0-15	9	0.318	159	6.26	672	26.46	8.1	0.32	8	17.64	150	2177
MA159-3	LWH159-10.0-15	10	0.353	159	6.26	735	28.94	8.1	0.32	8.8	19.40	150	2177
MA159-4	LWH159-11.0-15	11	0.388	159	6.26	797	31.38	8.1	0.32	9.4	20.72	150	2177
MA159-5	LWH159-12.0-15	12	0.424	159	6.26	860	33.86	8.1	0.32	10	22.05	150	2177
MA203-1	LWH203-12.0-15	12	0.424	203	7.99	587	23.11	10.3	0.41	12.9	28.44	150	2177
MA203-2	LWH203-15.0-15	15	0.530	203	7.99	702	27.64	10.3	0.41	14.9	32.85	150	2177
MA203-3	LWH203-20.0-15	20	0.706	203	7.99	900	35.43	10.3	0.41	18.1	39.90	150	2177
MA232-1	LWH232-20.0-15	20	0.706	232	9.13	840	33.07	11.7	0.46	24.9	54.90	150	2177
MA232-2	LWH232-30.0-15	30	1.059	232	9.13	1090	42.91	11.7	0.46	30.8	67.90	150	2177
MA232-3	LWH232-35.0-15	35	1.236	232	9.13	1215	47.84	11.7	0.46	33.5	73.85	150	2177
MA232-4	LWH232-40.0-15	40	1.413	232	9.13	1340	52.76	11.7	0.46	36.5	80.47	150	2177
MA232-5	LWH232-50.0-15	50	1.776	232	9.13	1590	62.60	11.7	0.46	42.3	93.26	150	2177
